Advantages and Features
Low Vibration
● Unequal flute spacing and variable helix angles reduce vibration.
● Large core diameter ensures high rigidity and prevents chatter.
Chipping Resistance
● Cutting edge protection prevents chipping.
Versatility
● Suitable for roughing, finishing, and semi-finishing, delivering excellent performance across various machining processes.
● Compatible with carbon steel, alloy steel, pre-hardened steel, and tool steel (HRC ≤ 45).
Nano-coating
● Heat-resistant, oxidation-resistant, and wear-resistant.
● Lowers the friction coefficient, reduces cutting heat, and prevents built-up edge (BUE) formation.
Parameter:
| NO. | R | L1 | DH6 | L |
|---|---|---|---|---|
| NOR-2B05450 | R0.5 | 2 | Φ4 | 50 |
| NOR-2B075450 | R0.75 | 3 | Φ4 | 50 |
| NOR-2B10450 | R1 | 4 | Φ4 | 50 |
| NOR-2B125450 | R1.25 | 5 | Φ4 | 50 |
| NOR-2B15350 | R1.5 | 6 | Φ3 | 50 |
| NOR-2B15450 | R1.5 | 6 | Φ4 | 50 |
| NOR-2B175450 | R1.75 | 7 | Φ4 | 50 |
| NOR-2B20450 | R2 | 8 | Φ4 | 50 |
| NOR-2B25550 | R2.5 | 10 | Φ5 | 50 |
| NOR-2B25650 | R2.5 | 10 | Φ6 | 50 |
| NOR-2B30650 | R3 | 12 | Φ6 | 50 |
| NOR-2B40860 | R4 | 16 | Φ8 | 60 |
| NOR-2B15375 | R1.5 | 6 | Φ3 | 75 |
| NOR-2B20475 | R2 | 8 | Φ4 | 75 |
| NOR-2B25575 | R2.5 | 10 | Φ5 | 75 |
| NOR-2B30675 | R3 | 12 | Φ6 | 75 |
| NOR-2B40875 | R4 | 16 | Φ8 | 75 |
| NOR-2B501075 | R5 | 20 | Φ10 | 75 |
| NOR-2B601275 | R6 | 24 | Φ12 | 75 |
| NOR-2B701480 | R7 | 28 | Φ14 | 80 |
| NOR-2B153100 | R1.5 | 6 | Φ3 | 100 |
| NOR-2B204100 | R2 | 8 | Φ4 | 100 |
| NOR-2B255100 | R2.5 | 10 | Φ5 | 100 |
| NOR-2B306100 | R3 | 12 | Φ6 | 100 |
| NOR-2B408100 | R4 | 16 | Φ8 | 100 |
| NOR-2B5010100 | R5 | 20 | Φ10 | 100 |
| NOR-2B6012100 | R6 | 24 | Φ12 | 100 |
| NOR-2B7014100 | R7 | 28 | Φ14 | 100 |
| NOR-2B8016100 | R8 | 32 | Φ16 | 100 |
| NOR-2B9018100 | R9 | 36 | Φ18 | 100 |
| NOR-2B1020100 | R10 | 40 | Φ20 | 100 |
| NOR-2B12525100 | R12.5 | 50 | Φ25 | 100 |
| NOR-2B306150 | R3 | 12 | Φ6 | 150 |
| NOR-2B408150 | R4 | 16 | Φ8 | 150 |
| NOR-2B5010150 | R5 | 20 | Φ10 | 150 |
| NOR-2B6012150 | R6 | 24 | Φ12 | 150 |
| NOR-2B7014150 | R7 | 28 | Φ14 | 150 |
| NOR-2B8016150 | R8 | 32 | Φ16 | 150 |
| NOR-2B9018150 | R9 | 36 | Φ18 | 150 |
| NOR-2B1020150 | R10 | 40 | Φ20 | 150 |
| NOR-2B12525150 | R12.5 | 50 | Φ25 | 150 |
